White-Rodgers 24A05E-1 208v Electric Heat Relay Single Level Temp-no Side View

White-Rodgers 24A05E-1 Electric Heat Relay (208 VAC)

Availability:

In-Stock

Baseboard Heater Low Voltage Contr
Item Low Voltage Control System
Type SPST, Normally Open, Single Level Temperature, Silent Operation
Size 4-1/2 Inch Width x 2-7/16 Inch Depth x 1-7/8 Inch Height
Used Onol System Item Baseboard Heater
Applicable Standard UL, CSA
Input Voltage 208 Volt AC at 60 Hertz
Thermostat Current 0.2 Amp
AC Resistive 5200 Watt 208 Volt 22 Amp
Motor Rating 12 Amp at 208 Volt (Full Load), 72 Amp at 208 Volt (Locked Rotor)
Ambient Temperature -20 to 140 Deg F
Lead Length 18 Inch
Average Time Delay 45 Second
