Taco 5124-C2 1" Sweat Mixing Valve (Low Lead)
The high flow, low head loss characteristics of the NSF 61 certified 5120 Series mixing valve make it ideal for use in the distribution of water through a domestic hot water system. The valves unique design and advanced thermostatic element ensures a stable mixed water temperature throughout the valves adjustable range.
Features
- NSF 61 Certified
- <.25% Lead
- Suitable for use in Potable Water
- High Flow
- Snap on Protective Cover
- No Routine Maintenance Required
$215.50 USD
SKU:
5124-C2
ID:
TC200-2S9-0147
Categories:
SPECIFICATIONS
| Bade Type | Forget Brass | |
| Application | Point of Source Point of Use | |
| Size | 1'' | |
| Connection Type | C x C | |
| Connection Method | Sweat | |
| Min Temp (F) | 85°F | |
| Max Temp (F) | 120°F |
| Max Pressure (PSI) | 200 | |
| Standards Met | NSF 60 ASSE 1017 ASSE 1070 | |
| Max Flow (GPM) | 20 | |
| Flow Capacity (Cv) | 1.37 | |
| Body Pattern | 3-Way | |
| Lead Free | Yes |
