Daikin 6 Ton 18.6 IEER / 12.5 EER R-32 70,000 Btu High-Static Commercial Gas Package Air Conditioner- DHG0723WL00001F
Product Overview
The Daikin DHG0723WL00001F is a 6‑ton light commercial packaged water‑source heat pump (WSHP) from the Daikin DHG series, designed for reliable year‑round heating and cooling in commercial spaces such as offices, retail stores, schools, and warehouses. This self-contained rooftop unit uses a water loop as the heat source and sink, delivering efficient and consistent performance while reducing energy consumption. It features R‑32 refrigerant, a two-stage scroll compressor, and a multi-speed ECM blower motor for improved part-load efficiency. The insulated cabinet and convertible airflow design allow flexible rooftop or ground installation, providing quiet, dependable comfort in a compact footprint.
Quick Facts
-
Model: DHG0723WL00001F
-
Product Type: Light Commercial Packaged Water-Source Heat Pump
-
Nominal Cooling Capacity: ~72,000 BTU / 6 Tons
-
Heating Capacity: ~80,000 BTU input (~65,000 BTU output)
-
Cooling Efficiency: ~16.2 SEER2 / ~12.2 EER2
-
Thermal Efficiency: ~81% AFUE
-
Compressor: Two-Stage Scroll
-
Refrigerant: R‑32 (low GWP)
-
Voltage/Phase: 208–230 V / 3‑Phase
-
Airflow: ~1,900–2,200 CFM nominal
-
Installation: Rooftop or ground mount with convertible airflow
-
Warranty: Typically ~5-year parts / ~20-year heat exchanger (varies by region)
$6,695.00 USD
SKU:
DHG0723WL00001F
ID:
HE101-2206
PRODUCT INFO
Standard Features
High-performance, low-noise two-stage scroll compressors, factory-mounted on rubber grommets for vibration isolation.
Refrigeration circuit includes high/low pressure safety switches; factory-charged with low GWP R‑32 refrigerant.
Direct-drive ECM airfoil supply fan with welded aluminum blades for quiet, efficient operation; dynamically balanced at the factory.
Integrated fan controls with thermal overload protection for reliable, low-maintenance operation.
Indoor draw-through coil with seamless copper tubes and aluminum fins for efficient dehumidification; factory pressure tested.
Large face-area outdoor coils; microchannel heat exchanger technology for improved performance and reduced refrigerant load.
ETL-certified heating modules with Wrinkle Bend Technology for enhanced heat transfer and durability.
Furnace with tubular in-shot gas burner and induced draft fan with airflow safety switch; fully integrated heating control.
Factory-wired 24V electromechanical controls with single-point power entry and terminal strips for easy installation.
Draw-through filter section using standard off-the-shelf filters for easy maintenance.
Cabinet Features
Tool-less filter access for easy maintenance.
Fully insulated cabinet with foil-faced fiberglass to prevent sweating and thermal loss.
1-inch raised flanges around supply and return.
Heavy-gauge galvanized steel perimeter base rail (≥3.5” tall) with rigging/lifting holes.
Electrical access through base or horizontal knockout for flexible installation.
SPECIFICATIONS
| Model Number(s) | DHG0723WL00001F |
| Brand | Daikin |
| Type | Gas Heat |
| Ton | 6.0 Ton |
| Cooling Btu | 69,000 |
| Cooling Stage(s) | 2 |
| Compressor Stage | Two |
| Voltage | 208/230V |
| Electrical Phase(s) | 3-Phase |
| Amp(s) | 40 |
| Maximum CFM | 2,100 |
| Refrigerant Type | R-32 |
| Height (Inches) | 53 3/4 |
| Length (Inches) | 74 |
| Width (Inches) | 48 5/16 |
| Total Shipping Weight (lbs.) | 690 |
| Parts Warranty (Years) | 5 |
| Compressor Warranty (Years) | 5 |
| UPC # | 633190265388 |
