Taco 0011-ZSF4 Stainless Steel Priority Zoning Circulator, 1/8 HP
Features
Typical Applications
Replacement Parts List:
Casing O-Ring: 009-005RP
Flange Gasket Set: 007-007RP
Cartridge Assembly Complete: 0011-010RP
- Universal Thermostat Compatibility, Thermostat Ready
- Can be used in conjunction with other circulators or zone valves
- Available in a full range of sizes from 003-0014
- 00 Reliability
- Snap-In PC Board
- Low and High Voltage Strips
- Removable low-voltage terminal strip simplifies wiring installation
- LED Power Light
- UL and CSA Listed
- 100% Factory Tested
- Made in USA
Typical Applications
- Indirect Hot Water Heaters
- Adding Zones
- Zoning with Circulators
- Prioritizing Under-Sized Zones
Replacement Parts List:
Casing O-Ring: 009-005RP
Flange Gasket Set: 007-007RP
Cartridge Assembly Complete: 0011-010RP
$1,328.00 USD
SKU:
0011-ZSF4
ID:
TC200-2S9-0627
Categories:
SPECIFICATIONS
| Material | Stainless Steel | |
| Application | Heating | |
| Max Pressure (PSI) | 125 | |
| Horse Power | 1/8 | |
| Flow Range (GPM) | 0-31 | |
| Max Flow (Ft) | 31 | |
| Hertz | 60 | |
| RPM | 3450 | |
| Connection Type | Flanged x Flanged |
| Amperage | 1.76 | |
| Voltage | 115V | |
| Type | Pump | |
| Connection Size | 1-1/4" 1-1/2" 1" | |
| Max Head (GPM) | 31 | |
| Head Range (ft.) | 0-31 | |
| Phase | 1 | |
| Temperature Range (F) | 40°F to 230°F |
