Turbo Air TCA381AE 4 Fan Center Mount Low Velocity Evaporator Coil (Unit Cooler)

• Features:
• Blue anti-corrosion-fin increases the life span of the coil.
• Air-pass guard is located at the bottom of the coil to improve heat exchange rate.
• Corrugated fin is used to increase heat exchange rate by expanding the surface area.
• Even in confined space, all parts can be reached easily by opening the front cover.
• Location of power connector makes replacement of motor convenient.
• Seamless inner groove copper tube increases the heat exchange rate by reducing
• the space between the fin and the copper tube.
• Venturi type distributor and precise orifice hole are used to minimize the pressure
• drop and maximize the freezing capacity respectively.
• Even in confined space, all parts can be reached easily by opening the front cover.
• Thermostat is installed to prevent over temperature on heater.
• Circuit opens automatically over 70ºF.
• Parts available:
  Expansion Valve (Sporlan) (Factory Pre-mounted)
  Solenoid Valve (Sporlan) (Factory Pre-mounted)
  Thermostat (Johnson Control) (Shipped Loose)
• The spiral fan guard enables cold air to be delivered efficiently and thoroughly.
• The protruding fan and motor placement substantially reduce vibration and noise.
• EC motor (Dual speed) for high energy efficiency.
• Anti-oxidizing stainless steel mounting and bolts
• 1 year parts and 1 year compressor warranty on condensing units and unit coolers.
• 4 year extended warranty available for compressor: total 5 years

Dimensions:

• A: 101.3 inch
• B: 89.3 inch
• C: 22.7 inch
• D: 22.0 inch
• E: 13.0 inch
• F: 14.2  inch
