Turbo Air TCE356B 5 Fan Low Velocity Center Mount Evaporator Coil (Unit Cooler)

Availability:
In-Stock
  •  BTU 35613@25F SST
  • Electric Defrost
  • PSC Motor
  • 1/15 HP
  • 208-230V/60Hz/1Ph
Available with or without TXV Kit (see button below)
Title

For pricing and to purchase this product:

Please register, login, or contact us for a quote request

PRODUCT INFO

Blue anti-corrosion-fin increases the life span of the coil. Air-pass guard is located at the bottom of the coil to improve heat exchange rate. Easy to replace defrost heater (LED model). Corrugated fin is used to increase heat exchange rate by expanding the surface area. Even in confined space, all parts can be reached easily by opening the front cover. Location of power connector makes replacement of motor convenient.

1 Year fan motor and parts warranty!

Seamless inner groove copper tube increases the heat exchange rate by reducing the space between the fin and the copper tube. Venturi type distributor and precise orifice hole are used to minimize the pressure drop and maximize the freezing capacity respectively. Even in confined space, all parts can be reached easily by opening the front cover.

  • Thermostat is installed to prevent over temperature on heater.
  • Circuit opens automatically over 50ºF.
  • Parts available: Expansion Valve (Sporlan) (Pre-mount option)
  • Solenoid Valve (Sporlan)
  • Thermostat (Johnson control)

The spiral fan guard enables cold air to be delivered efficiently and thoroughly. The protruding fan and motor placement substantially reduce vibration and noise. PSC fan motor, which prevents oil evaporation, is used for long life expectancy. EC motor (optional) for high energy efficiency. Unique air flow system (Patent pending) results in improved circulation within crowded walk-in cooler/freezer. Anti-oxidizing stainless steel mounting and bolts.

SPECIFICATIONS

  Capacity BTUH -20°F SST35613
  Fan CFM4310
  Fan No.5
  PSC Motor HP  1/15
  PSC Motor Total Amps1.75
  Line Set connections size Inlet1/2 OD
  Line Set connections size Suction1-1/2 OD
  Line Set connections size Drain3/8 MPT
  Approx. Net Wt. Lbs231
  Refrigerant TypeR404a,R448a,R449a,R407c
Dimensions see in Spec Sheet Attachment
