Tempro Industrial Line Voltage Thermostat, Polymeric Housing

Tempro TP517 Line Voltage Thermostat 30 to 110˚F Single Stg SPDT Polycarbonate Housing

Availability:

In-Stock

Line Voltage Thermostat ; Polycarbonate Housing
Switch type - Single Stg SPDT. Function - Heat & Cool
Temperature range : 30 to 110˚F. NEMA 4X.
UL CSA Approved.
Dimension - 5.75 x 2.25 x 2.25 in.
Additional Features - adjustable diff 3 to 12F

$138.00 USD

Default Title

Buy Now

Add to wishlist

SKU:

TP517

ID:

R410-0017

Categories:

REFRIGERATION / Refrigeration Controls / Temperature Controls

SPECIFICATIONS

	Basic Construction	Polycarbonate Housing
	Function	Heat & Cool
	Switch Type	Single Stg SPDT
	Temperature Range	30 to 110˚F
	Features	NEMA 4X
	Nickel plated sensing element	Yes
	UL Listed UL Listed to Canadian Safety Standards	Yes
	Electrical Ratings	120V/ 240V/ 277V AC
	Resistive	22/22/22A
	Inductive	16/8
	Locked Rotor	96/48
	Pilot Duty 24 to 600V AC	125VA
	Unit Carton
	Length (in.)	6.50
	Width (in.)	2.63
	Height (in.)	2.63

MANUALS

Tempro_Catalog
