RST-3002 | Programing Module compatible with IRU Ultrasonic Sensor

The RST-3002 Ultrasonic Sensor Programmer is used to program IRU Ultrasonic Sensors. The module connects your sensor to a computer with the IRU programming software installed.

Basic Programming Steps
Before programming, make sure your computer has the software downloaded and installed, and that the RST-3002 is connected to the USB Port.

Step 1: Connect the RST-3002 to your power source
Step 2: Connect the IRU Sensor to the RST-3002
Step 3: Launch Programming Software
Step 4: Make sure that 'USB' is selected in the Communications tab, then click on the 'Receive' button to populate the parameter fields.
After adjusting the parameters to your specifications, disconnect the IRU Sensor from the RST-3002, and connect it to either the X-420 or X-418 to begin montoring.

Features:

• Programs all IRU Sensors
• Includes USB Cable and Software

Compatible Products:
Connect the RST-3002 to one of the following products:

• IRU-3433
• IRU-2423
• IRU-5413

Ultrasonic Sensor Programmer RST-3002:

RST-3002

• Programmer for IRU ultrasonic sensors
• Includes: USB Cable and Software
