White-Rodgers 1311-103 1" Sweat Zone Valve (Three Wire)
- Hydronic Zone Valve
- Type 3-Wire
- Nominal Size 1 Inch
- Body Material Corrosion Resistant Stainless Steel
- Valve Timing 45 Second (Open/Close)
- Input Supply Rating 24 Volt AC 0.4 Amp
- Temperature Rating 240 Deg F
- Pressure Rating 50 PSI
- Media Handled Water
- Inclusions/Features Screw Terminal Wiring Panel, 24 Volt AC 2 Amp Auxiliary Switch
- Application Hydronic System
- Overall Dimension 4-5/8 Inch Width x 2-3/4 Inch Depth
- End to End Distance 3-1/8 Inch
- Flow Rate 37 Cv
$201.25 USD
SPECIFICATIONS
| Configuration | 3-Wire | |
| Conn.Size | 1'' | |
| Cv | 37.0 | |
| De-Energized-position | NC | |
| Sippnig Weight | 2.95 | |
| Shipping Width | 5.59 | |
| Shipping Length | 3.54 | |
| Shipping Height | 8.98 |
