Genteq Fan & Blower Motor, 1050 RPM, 1/3 HP, 120/240 V, 48 Frame, Open Air Over

Availability:
In-Stock
  • Evergreen VS - ECM Variable Speed Replacement Motor
  • 5.6" Diameter - 48 Frame
  • Electronically Protected
  • Ball Bearing
  • 1/2" Diameter Shaft with Flat
  • 36" Leads
  • HM108-0007 replaces the following brands and item numbers: Designed to replace Genteq constant airflow (variable speed) ECM indoor blower motors. Replaces Genteq models 2.3, EON, and 3.0 motors

$421.00 USD

Title
Buy Now
SKU:
6503V
ID:
HM108-1S9-0007

SPECIFICATIONS

Nameplate Specifications
UPC818508024721
Output HP1/3 Hp
Frequency60 Hz
Current5.0/2.8 A
Service Factor1
DutyContinuous Air Over
Frame48
Thermal ProtectionNo
ULNo
Voltage120/240 V
Speed1050 rpm
Phase1
Insulation ClassB
EnclosureOpen Air Over
Ambient Temperature40 °C
CSAN
Technical Specifications

Electrical TypeElectronically Commutated Motor
Poles12
MountingRound
Opp Drive End BearingBall
Shaft TypeFlat
Frame Length3.57 in
Shaft Extension5.00 in
RotationCounterclockwise/Clockwise
Frame MaterialRolled Steel
Overall Length10.71 in
Shaft Diameter0.500 in
