LPD Loop Powered Display (compatible with ControlByWeb devices)
The LPD Loop Powered Displays are designed to be inserted into a 4-20 mA sensor current loop to provide a local display without additional wiring. Setup is easy using the 3 buttons on the display.
$10,000.00 USD
SKU:
LPD-000001-C6-0-0-B81
Categories:
PRODUCT INFO
Loop Powered
The LPD is all about loop-powered circuits, perfect for installing just outside hazardous locations and displaying the readings from your intrinsic safety devices. The LPD has a 4-20 mA input and output.
Simplified User Interface
With just three buttons, and a large, two-line LCD display, using the LPD is straightforward and uncomplicated.
Optional Modbus RTU Programming
Alternatively, you can connect to the LPD from a PC running APG Modbus software via an RST programming module for quick and easy setup.
Features:
- Large, full 5-digit display with 0.4 in. characters and 6-digit description line
- Environmentally sealed housing; IP67 or IP68 certification
- 4-20 mA input
- Easy 3-button programming
- User selectable units of measure
