Hoshizaki KM-161BAJ 23-3/4" Crescent Cube, Self Contained Ice Machine, Air Cooled, 163 lb/24h, 115v

  • Ice Machine With Bin
  • Air-cooled
  • Self-contained condenser
  • Production capacity up to 163 lb/24 hours at 70°/50° (123 lb AHRI certified at 90°/70°)
  • 78 lb. built-in ice storage capacity
  • Crescent style cube
  • Front opening bin
  • Stainless steel exterior
  • 6" painted legs
  • 115v/60/1-ph, 7.1 amps, NSF, UL, cETLus, ADA Compliant

$3,388.00 USD

Buy Now


Featuring EverCheck™ technology, the Hoshizaki KM-161BAJ undercounter ice maker informs operators of system malfunctions quickly. With a simple on and off switch, this unit can be controlled without removing the panel. Its stainless steel exterior can be wiped clean, and its slide-in door supports quick content access. As many as 78 pounds of ice can be stored in the bin for peak business hours.

In ideal situations, the Hoshizaki KM-161BAJ undercounter ice maker produces as much as 163 pounds of crescent ice per day. In the self-contained condenser, air flows in and out the front, and its filter is removable for cleaning. The H-GUARD Plus Antimicrobial protects the ice scoop from bacteria buildup for clean ice.

Product Details:

  • 163-lb. maximum daily ice production
  • 123-lb. AHRI-certified daily ice production
  • 78-lb. storage capacity
  • Stainless steel exterior for durability
  • EverCheck technology alerts users of system malfunctions
  • Produces crescent cubes measuring 11⁄2 in. x 11⁄8 in. x 1⁄2 in.
  • Front-breathing, self-contained condenser
  • Condenser is air cooled with components that can be serviced quickly
  • Slide-in door for full access
  • Power switch operation
  • Runs with R134A refrigerant
  • Corrosion-resistant stainless steel evaporator
  • CycleSaver™ design makes a lot of ice each cycle
  • 6-in. legs
  • Ideal water temperature: 45-90 degrees F
  • Ideal ambient air temperature: 45-100 degrees F
  • 3,050-BTU heat transfer capacity
  • ADA compliant
  • UL, cETLus listed; NSF certified

Dimensions & Utilities:

  • 23.82 in. W x 28.43 in. D x 39 in. H
  • 7.1 A, 8.60 kW
  • 115 V/60 Hz/1 ph, 6.5-ft. cord with a NEMA 5-15P plug


Width23 3/4 Inches

Depth28 Inches

Height39 Inches

Amps 7.1 Amps

Hertz 60 Hertz

Phase1 Phase

Voltage115 Volts

24 Hour Ice Yield 123 - 163 Pounds

ADA Compliant Yes

Bin Storage Capacity 78 lb.

Condenser Type Air Cooled

Ice Type Crescent Cubes

Installation Type Self Contained

NSF Listed Yes

Power Usage 8.6 kWh per 100 lbs.

Type Ice Machines

Water Usage 23 Gallons per 100 lbs.
