ICM ICM518 Single Phase Surge Protection
Replaces: ASCO: 420120S; Eaton: SP1-240S, SP2-240S; ERICO (Critec): TDX50C240; Generac: G0073000; Intermatic: AG2401C3, IG1200RC3, IG1240RC3, IG3240RC3; Leviton: 55240-ASA; MARS: 83905; Siemons: TPS3A
$97.32 USD
SKU:
ICM518
ID:
PH501-2S9-3229
Categories:
PRODUCT INFO
Split Phase Surge Protective Device
The ICM518 is a UL Listed Whole-Home Surge Protective Device for 240 VAC Split-Phase configurations designed to protect a dwellings most valuable assets. It can be installed as a Type 1 (whole-home) or a Type 2 Surge Protective Device. Type 1 applications include installations before a service entrance or utility meter. Type 2 applications include installations after service entrances protecting particular equipment. The ICM518 has a NEMA Type 4X waterproof rated enclosure that is suitable for both indoor and outdoor use.
DETAILS:
- 240 VAC Split Phase Surge Protective Device
- Type 1 or Type 2 Whole Home SPD
- Easy 3-wire installation
- 3/4” conduit connection
- Maximum Surge Current: 100 kA
- Green LED indicator tells whether the device is operational
- Low cost, high performance
- Rugged and reliable
- UL Listed
- NEMA Type 4X watertight enclosure for indoor/outdoor use
- Surge protection technology: Thermally protected MOVs (TFMOV)
- Limited lifetime product, up to a 3-year $10,000 connected equipment warranty
SPECIFICATIONS
| General Information | |
| Service Voltage: | Split Phase 240 VAC |
| Short Circuit Current Rating (SCCR): | 200 kA |
| Nominal Discharge Current (In): | 20 kA |
| Maximum Surge Current: | 100,000 amps |
| SPD Type: | Type 1 (Can also be used in Type 2 applications) |
| Surge Protection Technology: | TFMOV |
| Protection Mode: | L1-L2, L1-N, L2-N L-L, 300VAC,L-N: 150VAC |
| Input Power Frequency: | 50/60 Hz |
| WEIGHT/DIMENSIONS: | 4.30” x 4.10” x 2.30” |
