Fasco Condenser Fan Motor, 825 RPM, 1/2 HP, 460 V, 48 Frame, Open Air Over

Availability:
In-Stock
  • Condenser Fan Motor
  • 5.6" Diameter - 48 Frame
  • Permanent Split Capacitor (PSC); Capacitor Required: 15 Mfd-370 Volts (Not Supplied with Motor)
  • Thermally Protected
  • Open Air Over
  • Class B Insulation, 60°C Ambient
  • Sleeve Bearing
  • 1/2" Diameter Shaft with Double Flat
  • 27" Leads
  • Belly Band

$499.00 USD

Title
Buy Now
SKU:
D920
ID:
HM101-1S9-0118

PRODUCT INFO

Applications
Primarily used in commercial rooftop air conditioning units

Features
Automatic thermal protection. Class B insulation systems. Lead end bell open all models, shaft end bell closed except as noted. Rotation: electrically reversible

SPECIFICATIONS

Nameplate Specifications
UPC818508020594
Output HP1/2 Hp
Frequency60 Hz
Current2.10 A
Service Factor1
DutyContinuous Air Over
Frame48
Thermal ProtectionThermally Protected
ULRecognized
Voltage460 V
Speed825 rpm
Phase1
Insulation ClassB
EnclosureOpen Air Over
Ambient Temperature60 °C
CSAY


Technical Specifications

Electrical TypePermanent Split Capacitor
Poles8
MountingRound
Opp Drive End BearingSleeve
Shaft TypeDouble Flat
Frame Length4.57 in
Shaft Extension4.00 in
RotationReversible
Frame MaterialRolled Steel
Overall Length:
10.13 in
Shaft Diameter0.500 in
